BEFORE THE ADAPTOR TAKING WE MUST A GIVE fuse
THE FUSE A fuse is simply a thin piece of wire.
But it can be designed to act quickly or slowly.
A "quick fuse" is called FAST ACTING and a "slow fuse" is called a DELAY FUSE.
A FAST ACTING fuse is also called a NORMAL FUSE.
It takes a lot of skill and knowledge to fit the correct fuse and also replace a fuse with the correct type.
A fuse doesn't really protect anything.
If a circuit gets overloaded, the fuse generally remains intact until one or more of the components "blows up" and the higher current heats the wire in the fuse and it melts.
The most common fuse in electronic work is 1 amp, 2 amp and 3 amp.
The rating "1 amp" is called the RATED CURRENT and is the current the fuse will handle for many years.
The term "FUSING CURRENT" is the value of current that will cause the fuse to melt. The time will depend on the construction of the fuse.
A normal fuse will allow about twice the rated current to flow and during this time the fuse can actually start to glow. This will oxidise the tin coating and the wire will gradually start to deteriorate. This will allow the fuse to fail at any time.
A DELAY FUSE is made with a piece of wire from one end and another from the other end and the two are soldered in the middle with a dot of solder.
If the two wires start to get hot, the solder melts and the wires separate.
This can happen at currents as low as 1.5 amp.
With fuses below 500mA, the wire is very thin and the current can gradually damage the coating and eventually it will fall apart for no reason.
As you can see, the fuse does not fail until at least 50% overload occurs and most transformers are not designed for this amount of overload.
Thus the transformer will fail and that's why some products have a 500mA fuse on the primary.
By the time the fuse fails, the transformer is "cooked."
The alternative to a fuse is a POLY SWITCH. This is covered in the next section.
Alternatively, a low value resistor can be used.
Sometimes a resistor is a good solution because, as the current increases to say twice the operating current, the power (heat) dissipated by the resistor will increase 4 TIMES.
This will damage any normal resistor.
PICO FUSES
PICO Industries developed a number of very small fuses with ratings from 100mA to 5 amp in a thin glass tube and having wires out each end so the fuse can be soldered to the PC board.
These small fuse became to be know as PICO FUSES and they are simply a "wire-in" fuse, contained in a very small glass tube.
Sometimes they are dipped and sealed.
Some of these fuses are hard to identify and difficult to determine the current rating.
You will need a multimeter to detect if the wire is intact. If is damaged, you will need to pull it apart and use a digital caliper to measure the diameter of the wire.
You will then need some new ones to pull apart and measure the diameter of the wire.
If there is a little spring inside the glass tube or a dob of solder, the fuse is a "SLOW-BLO" (DELAY) and it must be replaced with the same type.
A 1-amp "slow-blo" fuse will accept up to 3 amp for short periods of time and not get weakened because the wire is thicker than a normal 1 amp fuse. It works on the principle of the wire getting hot when 1.5 amps flows and the low-temperature solder melting.
When a power supply is turned ON, the electrolytics are uncharged and a very high current flow initially to charge them.
Both types of fuses will heat up during this time and you will be able to see the wire "sag" and then tighten again.
This process will gradually damage a normal fuse, whereas a delay fuse will not be affected.
There are hundreds of different types and styles of fuses for automotive, household, appliance and industrial protection.
If a fuse keeps blowing for no apparent reason, the first thing to do is refit the fuse up to 5 times and then use a delay fuse.
You cannot go to the next value as it will be 30% to 50% higher rating and the fuse you are already using is allowing up to 50% higher current to flow, before it fails.
If you fit a "stronger" fuse, the power supply may not be able to deliver sufficient current to activate the fuse and the equipment will "sit and burn" if a short-circuit develops.
Fuses in amplifiers are the hardest to replace because the amplifier takes a varying amount of current, according to the loudness of the music.
These fuses are generally "slow-blo" (delay) and the output wattage can be up to 10 times more than the average current when "loud thumping" is produced.
That's why you need to go by the manufacturers recommendation, as they have tested to equipment and come up with a value that does not prematurely fail.
This just a discussion to make you aware of the two different types of fuse and the approx current they are capable of handling.
AC FUSESThe current rating marked on the side of a fuse is DC CURRENT in AMPS.
There is no such thing as an "AC Fuse."
All fuses can be used in AC circuits.
In an AC circuit, the current will be say 1 amp for part of the cycle and less than 1-amp for the remainder of the cycle.
The heating effect on the wire inside the fuse will be exactly the same as a DC current of 1 amp.
This applies to all household fuses. A 10 amp fuse will allow 10 amps to flow and not be damaged or deteriorate. But what really happens is 14 amps will flow during the peak of the wave and less than 10 amps for the remainder of the cycle. The 14 amps is not present for long enough to overload the fuse.
Household fuses consisting of a length of wire are called "normal fuses."
A circuit breaker is called a FAST ACTING device and can be as fast a ONE CYCLE.
It detects excess current by producing magnetic flux from two turns of wire made from the conductor carrying the current. This magnetic flux is detected by a Hall device and a relay is activated to open the circuit. This is a totally different principle to a "hot wire" fuse.
DIFFERENT TYPES OF FUSES
These images show 5 in-line fuse holders,
then panel-mount fuse holders and fuse clips at the bottom
These images show blade fuses
Low-ohm surface-mount resistors can be used as a fuse because the current flowing through the resistor will create heat. The amount of heat is a product (multiplication) of the current flowing and the value of resistance. Basically you can say the wattage dissipated is four times greater when the current doubles. That's why it heats up and fails.
But there is a voltage drop across the resistor AT ALL TIMES and you must take this voltage drop into account when designing the project.
There is no voltage drop across a "normal" (wire) fuse.
But there is a voltage drop across the resistor AT ALL TIMES and you must take this voltage drop into account when designing the project.
There is no voltage drop across a "normal" (wire) fuse.
POLY SWITCH
Designing and testing circuits up to 1 amp has very few problems.
Most parts carrying 1 amp do not get very hot and the wiring can be light duty cable.
When the current is greater than 2 amp, you need to take additional precautions because the power supply you are using will deliver a high current and there is a high current flowing most of the time.
If you are using a power supply with current-limiting, use this feature, but if you are using a 12v battery, up to 100 amp can flow if a short-circuit is created. This will burn the leads and even the tracks on a PC board.
I am very careful whenever I use a 12v battery because two wires touching will burn out all the wiring.
There is a simple way to protect everything. It is called a FUSE.
It is the cheapest and best item.
You can use a 1amp, 2 amp or 3.15amp fuses
You can also use a circuit breaker.
You can find a 10 amp circuit breaker in a damaged power board. Just pull the power board apart and re-use the circuit breaker.
Finally you can use a POLY SWITCH.
This is a crystalline structure that has a very low resistance (something like 0.05 ohms). When a current flows through the structure it gets slightly warm. When a higher current flows, it gets slightly warmer and its resistance increases.
This causes more heat to be produced (by the structure) and it gets hotter and hotter. Within a very short period of time its resistance is very high and only a very small current flows.
This current is called "Leakage Current" and can be from 20mA to 100mA.
The voltage of the supply and the leakage current will create heat in the device to keep it in a state of high resistance.
A Poly Switch can take from 10mS to 10 seconds to activate (respond) and this depends on the voltage of the supply and the short-circuit current (the voltage of the supply has an effect on the maximum current flowing).
You need to remove the supply and wait a few seconds for the Poly Switch to cool down.
But there is one more thing to remember about a Poly Switch. It also has a VOLTAGE RATING.
When the Poly Switch "goes open" the voltage of the supply will effectively be across the device and if it is rated for 30v and the supply is 100v, the device will breakdown due to the overvoltage and it will either leak more current or breakdown completely and deliver a lot more current to the "short."
Understanding how this device works needs a lot more understanding than first meets the eye and is actually a "final year" component consideration as you would need to buy a number of different types and work out which is the most suitable.
In most cases the current-rating of the device (say 1 amp) is the normal current for the device and it will go open when twice this current ( 2 amps) flows. You have to decide if the "trip current" will protect the product you are designing.
All the protection devices mentioned above will prevent the leads burning out but nothing will protect any of the electronic components from being damaged.
Here are 3 ways to protect your project from going "up in smoke!"
