ANTENNA BASIC CONCEPTS
ANTENNA
An antenna is a device to transmit and/or receive electromagnetic waves. Electromagnetic waves are often referred to as radio waves. Most antennas are resonant devices, which operate efficiently over a relatively narrow frequency band. An antenna must be tuned (matched) to the same frequency band as the radio system to which it is connected, otherwise reception and/or transmission will be impaired.
WAVELENGTH
We often refer to antenna size relative to wavelength. For example: a 1/2 wave dipole is approximately half a wavelength long. Wavelength is the distance a radio wave travels during one cycle. The formula for wavelength is:
λ = c f Where: λ is the wavelength expressed in units of length, typically meters, feet or inches c is the speed of light (11,802,877,050 inches/second) f is the frequency
For example: wavelength in air at 825 MHz is 11.803 X 109 in./sec = 14.307 in. 825 x 106 cycles/sec
Note: The physical length of a half-wave dipole is slightly less than half a wavelength due to end effect. The speed of propagation in coaxial cable is slower than in air, so the wavelength in the cable is shorter. The velocity of propagation of electromagnetic waves in coax is usually given as a percentage of free space velocity, and is different for different types of coax.
IMPEDANCE MATCHING
For efficient transfer of energy, the impedance of the radio, the antenna and the transmission line connecting the radio to the antenna must be the same. Radios typically are designed for 50 Ohms impedance, and the coaxial cables (transmission lines) used with them also have 50 Ohms impedance. Efficient antenna configurations often have an impedance other than 50 Ohms. Some sort of impedance matching circuit is then required to transform the antenna impedance to 50 Ohms. Larsen antennas come with the necessary impedance matching circuitry as part of the antenna. We use low-loss components in our matching circuits to provide the maximum transfer of energy between the transmission line and the antenna.
VSWR AND REFLECTED POWER
Voltage Standing Wave Ratio (VSWR) is an indication of the quality of the impedance match. VSWR is often abbreviated as SWR. A high VSWR is an indication the signal is reflected prior to being radiated by the antenna. VSWR and reflected power are different ways of measuring and expressing the same thing.
A VSWR of 2.0:1 or less is often considered acceptable. Most commercial antennas are specified to be 1.5:1 or less over some bandwidth. Based on a 100 watt radio, a 1.5:1 VSWR equates to a forward power of 96 watts and a reflected power of 4 watts, or the reflected power is 4.2% of the forward power.
BANDWIDTH
Bandwidth can be defined in terms of radiation patterns or VSWR/reflected power. The definition used is based on VSWR. Bandwidth is often expressed in terms of percent bandwidth, because the percent bandwidth is constant relative to frequency. If bandwidth is expressed in absolute units of frequency, for example MHz, the bandwidth is then different depending upon whether the frequencies in question are near 150 MHz, 450 MHz or 825 MHz.
DECIBELS
Decibels (dB) are the accepted method of describing a gain or loss relationship in a communication system. The beauty of dB is they may be added and subtracted. A decibel relationship (for power) is calculated using the following formula.
dB = 10 log Power A Power B
“A´ might be the power applied to the connector on an antenna, the input terminal of an amplifier or one end of a transmission line. “B´ might be the power arriving at the opposite end of the transmission line, the amplifier output or the peak power in the main lobe of radiated energy from an antenna. If “A´ is larger than “B´, the result will be a positive number or gain. If “A´ is smaller than “B´, the result will be a negative number or loss.
Example:
At 1700 MHz, one fourth of the power applied to one end of a coax cable arrives at the other end. What is the cable loss in dB?
In the above case, taking the log of 1/4 (0.25) automatically results in a minus sign, which signifies negative gain or loss. It is convenient to remember these simple dB values which are handy when approximating gain and loss:
Power Gain Power Loss 3 dB = 2X power – 3 dB = 1/2 power 6 dB = 4X power – 6 dB = 1/4 power 10 dB = 10X power -10 dB = 1/10 power 20 dB = 100X power -20 dB = 1/100 power
In the case of antennas, passive structures cannot generate power. dB is used to describe the ability of these structures to focus energy in a part of space.
DIRECTIVITY AND GAIN
Directivity is the ability of an antenna to focus energy in a particular direction when transmitting or to receive energy better from a particular direction when receiving. There is a relationship between gain and directivity. We see the phenomena of increased directivity when comparing a light bulb to a spotlight. A 100-watt spotlight will provide more light in a particular direction than a 100-watt light bulb and less light in other directions. We could say the spotlight has more “directivity´ than the light bulb. The spotlight is comparable to an antenna with increased directivity. Gain is the practical value of the directivity. The relation between gain and directivity includes a new parameter (η) which describes the efficiency of the antenna.
G = η • D
For example an antenna with 3 dB of directivity and 50% of efficiency will have a gain of 0 dB.
GAIN MEASUREMENT
One method of measuring gain is to compare the antenna under test against a known standard antenna. This is known as a gain transfer technique. At lower frequencies, it is convenient to use a 1/2-wave dipole as the standard. At higher frequencies, it is common to use a calibrated gain horn as a gain standard with gain typically expressed in dBi.
Another method for measuring gain is the 3-antenna method. Transmitted and received powers at the antenna terminal are measured between three arbitrary antennas at a known fixed distance. The Friis transmission formula is used to develop three equations and three unknowns. The equations are solved to find the gain expressed in dBi of all three antennas.
Pulse-Larsen uses both methods for measurement of gain. The method is selected based on antenna type, frequency and customer requirement.
Use the following conversion factor to convert between dBd and dBi: 0 dBd = 2.15 dBi. Example: 3.6 dBd + 2.15 dB = 5.75 dBi
RADIATION PATTERNS
Radiation or antenna pattern describes the relative strength of the radiated field in various directions from the antenna at a constant distance. The radiation pattern is a “reception pattern´ as well, since it also describes the receiving properties of the antenna. The radiation pattern is three-dimensional, but it is difficult to display the three-dimensional radiation pattern in a meaningful manner. It is also time-consuming to measure a three-dimensional radiation pattern. Often radiation patterns measured are a slice of the three-dimensional pattern, resulting in a two-dimensional radiation pattern which can be displayed easily on a screen or piece of paper. These pattern measurements are presented in either a rectangular or a polar format.
ANTENNA PATTERN TYPES
OMNIDIRECTIONAL ANTENNAS
For mobile, portable and some base station applications the type of antenna needed has an omnidirectional radiation pattern. Omnidirectional antennas radiate and receive equally well in all horizontal directions. The gain of an omnidirectional antenna can be increased by narrowing the beamwidth in the vertical or elevation plane. The net effect is to focus the antenna´s energy toward the horizon.
Selecting the right antenna gain for the application is the subject of much analysis and investigation. Gain is achieved at the expense of beamwidth. Higher-gain antennas feature narrow beamwidths while the opposite is also true. Omnidirectional antennas with different gains are used to improve reception and transmission in certain types of terrain. A 0 dBd gain antenna radiates more energy higher in the vertical plane to reach radio communication sites located in higher places. Therefore they are more useful in mountainous and metropolitan areas with tall buildings. A 3 dBd gain antenna is a good compromise for use in suburban and general settings. A 5 dBd gain antenna radiates more energy toward the horizon compared to the 0 and 3 dBd antennas. This allows the signal to reach radio communication sites further apart and less obstructed. Therefore they are best used in deserts, plains, flatlands and open farm areas.
DIRECTIONAL ANTENNAS
Directional antennas focus energy in a particular direction. Directional antennas are used in some base station applications where coverage over a sector by separate antennas is desired. Point-to-point links also benefit from directional antennas. Yagi and panel antennas are directional antennas.
BEAMWIDTH
Beamwidth describes the angular aperture where the most important part of the power is radiated. In general, we talk about the 3 db beamwidth which represents the aperture (in degrees) where more than 90% of the energy is radiated.
For example, for a 0 dB gain antenna, 3 db beamwidth is the area where the gain is higher than –3 dB.
NEAR-FIELD AND FAR-FIELD PATTERNS
The radiation pattern in the region close to the antenna is not exactly the same as the pattern at large distances. The term “near-field´ refers to the field pattern existing close to the antenna. The term “far-field´ refers to the field pattern at large distances. The far-field is also called the radiation field, and is what is most commonly of interest. The nearfield is called the induction field (although it also has a radiation component).
Ordinarily, it is the radiated power that is of interest so antenna patterns are usually measured in the far-field region. For pattern measurement, it is important to choose a distance sufficiently large to be in the far-field, well out of the near-field. The minimum permissible distance depends on the dimensions of the antenna in relation to the wavelength. The accepted formula for this distance is:
ANTENNA POLARIZATION
Polarization is defined as the orientation of the electric field of an electromagnetic wave. Two often-used special cases of elliptical polarization are linear polarization and circular polarization. Initial polarization of a radio wave is determined by the antenna launching the waves into space. The environment through which the radio wave passes on its way from the transmit antenna to the receiving antenna may cause a change in polarization.
With linear polarization the electric field vector stays in the same plane. In circular polarization the electric field vector appears to be rotating with circular motion about the direction of propagation, making one full turn for each RF cycle. The rotation may be right-hand or left-hand.
Choice of polarization is one of the design choices available to the RF system designer. For example, low frequency (<1 MHz) vertically polarized radio waves propagate much more successfully near the earth than horizontally polarized radio waves because horizontally polarized waves will be cancelled out by reflections from the earth. Mobile radio system waves generally are vertically polarized. TV broadcasting has adopted horizontal polarization as a standard. This choice was made to maximize signal-to-noise ratios. At frequencies above 1 GHz, there is little basis for a choice of horizontal or vertical polarization, although in specific applications there may be some possible advantage in one or the other. Circular polarization has also been found to be of advantage in satellite applications such as GPS. Circular polarization can also be used to reduce multipath.
DETERMINING WHIP LENGTH
In general, whip length is defined as a fraction of the wavelength and depends on the electrical characteristics you want to achieve. Theoretically, a whip provides an omnidirectional pattern in the horizontal plane and a dipolar pattern in the elevation plane. When you increase the whip length by a fraction of a wavelength (commonly /14 wavelength), you increase the gain of the structure by reducing the aperture in the elevation plane.
DETERMINING GROUND PLANE SIZE
For many types of antennas the theoretical analysis is based on the use of an infinite ground plane. In practice, this condition is never achieved. Common effects of reduction of the size of the ground plane are:
– Electrical tilt: The maximum energy is not radiated in the expected direction.
– Beamwidth Increased: The aperture of the radiating element is modified, and the gain of the antenna is decreased.
In conclusion, we could say the bigger the ground plane, the better the control of the electrical performance of the antenna.
BASIC ANTENNA TYPES
The following discussion of antenna types assumes an “adequate´ ground plane is present.
1/4 WAVE
A single radiating element approximately 1/4 wavelength long. Directivity 2.2 dBi, 0 dBd.
LOADED 1/4 WAVE
The loaded 1/4 wave antenna looks electrically like a 1/4 wave antenna but the loading allows the antenna to be physically smaller than a 1/4 wave antenna. Quite often this is implemented by placing a loading coil at the base of the antenna. Gain depends upon the amount of loading used. Directivity 2.2 dBi, 0 dBd.
1/2 WAVE
A single radiating element 1/2 wavelength long. Directivity 3.8 dBi, 1.6 dBd. A special design is the end fed 1/2 wave.
5/8 WAVE
A single radiating element 5/8 wavelength long. Directivity 5.2 dBi, 3.0 dBd.
COLLINEAR
Two or three radiating elements separated by phasing coils for increased gain. Four common styles are:
1) 5/8 over 1/4: The top element is 5/8 wave and the bottom element is 1/4 wave. Directivity 5.4 dBi, 3.2 dBd. 2) 5/8 over 1/2: The top element is 5/8 wave and the bottom is 1/2 wave. Directivity 5.6 dBi, 3.4 dBd. 3) 5/8 over 5/8 over 1/4: The top 2 elements are 5/8 wave and the bottom element is 1/4 wave. Directivity 7.2 dBi, 5.0 dBd. 4) 5/8 over 5/8 over 1/2: The top 2 elements are 5/8 wave and the bottom element is 1/2 wave. Directivity 7.6 dBi, 5.4 dBd.
Using more than three radiating elements in a base-fed collinear configuration does not significantly increase gain. The majority of the energy is radiated by the elements close to the feed point of the collinear antenna so there is only a small amount of energy left to be radiated by the elements which are farther away from the feed point.
Please note the directivity is given above for common antenna configurations. Gain depends upon the electrical efficiency of the antenna. Here is where the real difference between antenna manufacturers is seen. If you cut corners in building an antenna, the gain may be significantly lower than the directivity. Larsen uses low-loss materials to minimize the difference between the gain and the directivity in our antennas.
WHIP
The vertical portion of the antenna assembly acting as the radiator of the radio frequency
GPS
Active GPS antennas include an amplifier circuit in order to provide better reception of the satellite signal. This active stage generally includes a low noise amplifier and a power amplifier.
Combi GPS/Cellular structures include several antennas in one radome to allow reception and transmission in different frequency bands.
DIPOLE
An antenna – usually 1/2 wavelength long – split at the exact center for connection to a feed line. Dipoles are the most common wire antenna. Length is equal to 1/2 of the wavelength for the frequency of operation. Fed by coaxial cable.
Sleeve Dipoles are realized by the addition of a metallic tube on a coaxial structure.
Printed Dipoles have a radiation structure supported by a printed circuit.
EMBEDDED OMNI
Embedded omni antennas are generally integrated on a base for applications such as access points. This structure could be externally mounted (ex: sleeve dipole) or directly integrated on the PC board of the system (ex: printed dipole).
YAGI
A directional, gain antenna utilizing one or more parasitic elements. A yagi consists of a boom supporting a series of elements which are typically aluminum rods.
PANEL
Single Patch describes an elementary source obtained by means of a metallic strip printed on a microwave substrate. These antennas are included in the radiating slot category.
Patch Arrays are a combination of several elementary patches. By adjusting the phase and magnitude of the power provided to each element, numerous forms of beamwidth (electric tilt, sectoral, directional . . .) can be obtained.
Sectoral antennas can be depicted like a directive antenna with a beamwidth greater than 45°. A 1 dB beamwidth is generally defined for this kind of radiating structure.
OMNI CEILING MOUNT
Omni ceiling mount antennas are used for the propagation of data in an in-building environment. In order to provide good coverage, these antennas are vertically polarized and present an omnidirectional pattern in the horizontal plane and a dipolar pattern in the vertical plane.
PARABOLIC
An antenna consisting of a parabolic reflector and a radiating or receiving element at or near its focus. Solid Parabolics utilize a dish-like reflector to focus radio energy of a specific range of frequencies on a tuned element. Grid Parabolics employ an open-frame grid as a reflector, rather than a solid one. The grid spacing is sufficiently small to ensure waves of the desired frequency cannot pass through, and are hence reflected back toward the driven element.
PULSE-LARSEN ANTENNA TYPES
Mobile: Collinear, Whip, Low Profile, Active GPS, Combi GPS/Cellular
Base Station: Whip, Collinear, Yagi, Panel, In-building Sectoral, Omni-ceiling Mount
MOBILE ANTENNA PLACEMENT
Correct antenna placement is critical to the performance of an antenna. An antenna mounted on the roof of a car will function better than the same antenna installed on the hood or trunk. Knowledge of the vehicle may also be an important factor in determining what type of antenna to use. Do not install a glass mount antenna on the rear window of a vehicle in which metal has been used to reduce ultraviolet light. The metal tinting will work as a shield and not allow signals to pass through the glass.
Antenna Design Grows Up
Apple’s iPhone 4 antenna issue represents a classic example of what can go wrong in modern antenna design. Put one in the wrong place, and a seemingly insignificant part can turn a cool new product into a public relations nightmare.
Ever since antennas dropped out of sight, most consumers don’t give them a second thought. In the 1960s, almost every home had a rooftop antenna. Fast forward to the present and most devices are connected either by cable or wirelessly. The antennas are still there, but they’re no longer visible. And they’re even more important than before, and significantly more complicated to design. Fig. 1. Rooftop antennas once dominated the landscape.
“It’s a very complex issue becoming more complex. Automotive, unequivocally, is the most complex system for any wireless engagement from an antenna placement, selection, management perspective,” noted Richard Barrett, senior product marketing engineer, automotive wireless technology at Cypress Semiconductor. “I can’t think of any industry that would even approach the complexities of automotive, outside of something like aerospace or military. Automotive is more complex because of the many models that you have in a consumer industry.”
Engineers have to start off with understanding what their limitations are, and what they need to work with in order to find the optimal solution, he said. “Some of the basic fundamentals are there, and so many electronics are being packed into a vehicle, where the radio is going to exist in the vehicle will change dramatically. It can be in metal enclosures, behind firewalls, and coexist with other radios or emissive devices around it, which is a huge challenge unto itself. In addition, temperature considerations are driving whether things are on the roof, in the mirror, inside infotainment or inside of an engine compartment. This will also define what can be done with the radios, and so forth.”
Placement is key for antennas, and the best location generally is where there is the least influence from the environment on performance.
“Ideally, antennas placed in their intended operational environment should perform just as they usually do when they’re designed in isolation—without anything around them,” said Shawn Carpenter, high frequency product manager at Ansys. “However, the reality is that the desire for integrated product size reduction, aesthetics that are pleasing to consumers, and a simple lack of real estate for isolating integrated antennas lead to compromises of antenna performance.”
This performance impact usually comes from coupling to other parts of the product, platform or vehicle into which the antenna is installed. Platform features such as limited ground planes, batteries, curved surfaces, material coatings and paints, and supporting structures can couple unintended energy from the antenna and change the way it radiates and/or accepts power. As a result, the antenna design needs to factor the placement effects of the antenna into its basic design, compensating for the potential performance induced by the environment.
The best placement for an antenna also depends upon the intended use of the antenna, Carpenter said. “In some situations, the orientation of the product, platform or vehicle into which the antenna is installed can vary over time, so we require the antenna to radiate and receive in all directions as equally as possible.” Fig. 2: Radiation gain in antennas frequently deviates from ideal isotropic behavior. Source: Cypress.
Consider an antenna integrated into a mobile phone. The phone’s orientation can vary continuously, and the phone needs to have continual contact with the nearest cell tower. If the mobile phone’s antenna has weak gain in the direction of the cell tower, then the weakness in that link has to be made up by using more transmit power, or by increasing the sensitivity of the receiver, which lead in turn to reduced battery life.
Then, for omnidirectional antennas, the antenna should be placed in a location where its radiation pattern will be as undisturbed as possible, which usually means placing it as far away from other conductors as possible. This runs counter to the frequent requirement that the overall product (containing the antenna) be as small as possible. Designers faced with these challenges will generally incorporate an antenna on an edge or side of such a product, and try to anticipate the effects of near-field coupling (the antenna coupling placement effects) to other parts of product or vehicle in the overall antenna design, he observed. Fig. 3: Multiple antennas in a device. Source: ANSYS.
“Other antennas are intended to be directional in nature—they are intended to reliably concentrate power in a specific direction. Such antennas can be quite sensitive to coupling to nearby structures, which can in turn reduce the antenna’s ability to concentrate power in a specific direction. If this antenna’s directionality is reduced, then more transmit power would be needed to overcome the loss in link gain, and the receiver will have higher susceptibility to signals coming from unintended directions. Proper location of directional antennas has long been a concern of antenna systems engineers because of the environment’s impact on the overall performance of the RF system,” Carpenter said. System-level perspective
A further mitigating complexity with automotive that isn’t seen elsewhere is that the core design team at the automotive OEM that’s developing a solution can design essentially the core electronics, the core box that has the radios (WiFi, Bluetooth, LTE), and can give some recommendations on how antennas should be placed, and implemented.
“But at the end of the day, they don’t necessarily control that because then it goes to a vehicle model,” Barrett said. “Taking the most extreme example, let’s look at a company like a GM. The same exact system that’s developed by a core engineering team within General Motors may be deployed in a Chevy Volt or a Cadillac Escalade ESV. It varies widely on what it’s physically going into. As a result, that engineering team can’t predict what the RF environment is going to look like in the end model, or what the placement of the box is going to be, and how they will have to route to antennas. No other system is like this. You buy a phone and the phone designers know exactly what was going into it and what it will be used for. But cars vary so dramatically, and everything that’s ugly for any electronics — wireless in particular, whether it’s environmental or RF emissions or just metal shielding — everything in the way is just compounded,” he said. Fig. 4: Mixed signals. Source: ANSYS.
Further complicating matters is that fact there probably will be conflict between the antenna and other devices that are transmitting or receiving.
“You’re pretty much guaranteed to have conflict,” according to Michael Thompson, senior solutions architect at Cadence. “At least when I design an automobile, I can take that into account because I know where I’m going to place those antennas, and there are some unique things that happen inside of a car because of the Faraday cage. Depending on whether the antenna is on the inside or the outside of it, and whether or not there is coupling around the car, all of those things can be modeled in order to make provisions up front to make sure there isn’t coupling, or least minimizing or filtering it.”
The larger issue going forward will be when everyone starts to have multiple radars in their cars, Thompson said. “How do we know that the signal you’re getting back is the signal you transmitted for your radar, or some other signal, and not somebody else’s car? Interference is a different type of problem, but it can obviously happen. It’s a completely different market, but electronic warfare is all based on putting out signals to fool/feign some other response. That can be managed by some of the signal processing behind the antenna, but the antenna can’t sort out what’s a good signal and what’s a bad one. All it knows it that it receives this energy at a certain frequency, from a certain area. It absorbs that energy, and passes it onto the receiver.”
To address these issues, the best that chipmakers can do is provide recommendations. “If you’re in a metal box, you have to cut a slot in the box so there’s someplace for the RF to get into,” said Barrett. “It’s got to be able to see outside. If you can cable outside to an outside antenna, that’s a great idea.”
And then there is the issue of how much an antenna design will cost.
“Everyone would like to be able to use a cheap Inverted F printed circuit board antenna to do everything in the world, but that’s just from the cost side of things,” he said. “From the engineering side, you’d love to have nice dipole antennas, cabled out to the most optimal location, end cabin use, facing the consumer. And for external vehicle, you want that facing outside the car in the proper direction. Those are the two extremes. The real world is somewhere in the middle.”
The considerations are many, driven by the complexity of different vehicle models, as well as complexity of use cases. Some systems primarily look outside the car (like an LTE modem), but WiFi and Bluetooth can look inside and outside of the car.
“Do you optimize for the passengers? Do you optimize to connect to an external access point? Are you trying to have a hybrid approach, which when you get to engineering tradeoffs means nothing is optimized? Those are huge challenges that you see across the market,” Barrett noted. “To try to address this, there are more cabled systems [available commercially], because at least if you cable out to an antenna then you’ve got some control over where that antenna sits relative to, say, passengers or external to the car. Although you can’t control the length of the cable many times, and know exactly what the RF is going to look, at least you’ve got a little more control there. You can clear the space between wherever your radio is radiating through its antenna to wherever its trying to radiate, and receive or transmit to/from.”
There are both in-cabin, and external considerations. Thankfully, performance in-cabin is not as critical. Antennas generally are close to each other, so the standard WiFi and Bluetooth technologies probably shouldn’t be too sensitive or transmitting at too high a power because it can be kept localized.
“However, there are so many applications now that also need to connect outside the vehicle, whether for an LTE modem connecting to a WiFi access point, you want to offload it to WiFi, the faster you can connect to that external WiFi as you’re in slow moving traffic, the more time there will be on that access point to dwell on it. The stronger signal there is, the better link budget from a receiver sensitivity or transmit power out standpoint the longer you’ll be able to maintain connection on that box,” he added.
Over-the-air upgrades are another area that can be impacted. For these, a vehicle may be sitting in a garage and the media server in the house is automatically downloading to the vehicle to upgrade the software, just like a smartphone. Because of varying sizes of homes, and depending on construction method, the RF environments have to be considered as well, so placement of antennas for external applications, and maximizing that link budget is critical. It all comes down to predictability of what can be controlled in the RF, what the vehicle looks like, and willingness to spend money on a decent antenna. Algorithms, techniques
Then, when it comes to analyzing the system, there are a number of technologies that have existed for some time, Thompson said. “We keep finding better ways to calibrate them, and implementing them in a computer architecture so they run better, but a lot of those techniques have been around for many years. They do work quite well, but you have to be able to very accurately describe the physical reality that you’re going to be operating in to the simulator, and that often becomes part of the problem.”
Working out the best way to create that description, much like antenna design itself, depends on what is being analyzed, Thompson explained. “If I am looking at radiation issues, for example, not only from real antennas but just from the circuitry — EMI/EMC — those types of issues arise from the fact that the circuit is radiating. If you design an antenna at some particular frequency, and it’s working really great at that frequency, just because it was designed at that frequency doesn’t mean it won’t radiate at another frequency. The same holds true for the circuit board. From that standpoint, a lot of times, planar tools, techniques like Method of Moment, run faster and have the capacity, so you’d want to have something like that available to the designer. At the same time, you may be looking at bond wires, connectors, 3D effects so something more like a finite element method is more appropriate; an environment that could handle multiple electromagnetic techniques is really what the designer needs.”
ANSYS, CST, Antenna Magnus, and Mathworks, among others, all provide tools in this area. Cadence has indicated it is looking into this space with key partners. Tools from Cadence, Mentor Graphics, Synopsys, and other EDA providers have been used in the simulation of antenna design for some time. Conclusion
Antenna design today is still part black art, but that is about to change given its role in the IoT and automotive arenas. Future design approaches will draw on knowledge about a design from many sources, not just the previous experience of a design team. That collection of data points will find its way into whatever tools are being used to design, verify and optimize antennas for each unique situation. Demand is rising along with the complexity of the antenna designs, and changes are coming quickly in this space.
